FTF 13 - Fittipaldi Offroad

Alpha Series

FTF 13

FORGED

U.S. PATENT NO. D863,187

  • DIAMETERS: 22"/ 24"
  • WIDTHS: 12"/14"
  • BOLT PATTERNS: 5x5 / 6x135 / 6x5.50 / 8x6.50 / 8x170

STANDARD FINISHES:

  • 26 BLACK MILLED (BM)
  • 27 POLISHED (P)

AVAILABLE SIZES AND LIVE INVENTORY

[] CLICK TO EXPAND

Alpha Series

FTF 13

PartNumberSizeBolt CircleOffset (mm)Back SpacingLoad RatingHub Bore (mm)Inventory
FTF13-22125127N51BM22X125X5.00-514.49250071.50mm5
FTF13-22126135N51BM22X126X135-514.49250087.10mm3
FTF13-22126139N51BM22X126X5.50-514.49250078.10mm2
FTF13-22128165N51BM22X128X6.50-514.493500125.20mm1
FTF13-22128170N51BM22X128X170-514.493500125.20mm4
FTF13-22125127N51PL22X125X5.00-514.49250071.50mm1
FTF13-22126135N51PL22X126X135-514.49250087.10mm4
FTF13-22126139N51PL22X126X5.50-514.49250078.10mm4
FTF13-22128165N51PL22X128X6.50-514.493500125.20mm0
FTF13-22128170N51PL22X128X170-514.493500125.20mm0
FTF13-22146135N76BM22X146X135-764.51250087.10mm0
FTF13-22146139N76BM22X146X5.50-764.51250078.10mm1
FTF13-22148165N76BM22X148X6.50-764.513500125.20mm4
FTF13-22148170N76BM22X148X170-764.513500125.20mm1
FTF13-22146135N76PL22X146X135-764.51250087.10mm6
FTF13-22146139N76PL22X146X5.50-764.51250078.10mm0
FTF13-22148165N76PL22X148X6.50-764.513500125.20mm0
FTF13-22148170N76PL22X148X170-764.513500125.20mm4
FTF13-24126135N51PL24X126X135-514.49250087.10mm2
FTF13-24126139N51PL24X126X5.50-514.49250078.10mm3
FTF13-24128165N51PL24X128X6.50-514.493500125.20mm0
FTF13-24128170N51PL24X128X170-514.493500125.20mm0
FTF13-24146139N76BM24X146X5.50-764.51250078.10mm5
FTF13-24148165N76BM24X148X6.50-764.513500125.20mm4
FTF13-24148170N76BM24X148X170-764.513500125.20mm4
FTF13-24146139N76PL24X146X5.50-764.51250078.10mm4
FTF13-24148165N76PL24X148X6.50-764.513500125.20mm4
FTF13-24148170N76PL24X148X170-764.513500125.20mm0
